Overall parameters:
Overall product size: 600 * 2700 * 130mm
Three color arrow lamp: 400 * 400mm
Full color outdoor screen: p5480 * 1120mm
Waterproof box: high sunscreen and high toughness
Box structure: inner and outer double-layer sealed box
Screen features: high brightness, low power consumption, high sunscreen, high waterproof and high toughness
Usage scenario: highway, expressway and crowded place
Outdoor P5 LED screen parameters:
No. |
Item | Parameters |
1 |
Display screen size | 480*1120mm |
2 |
Product model | FS5 |
3 |
Dot pitch | P5 |
4 |
Pixel density | 40000 |
5 |
LED bulb | 1R1G1B |
6 |
LED bulb model | SMD1921 |
7 |
Model size | 160*160mm |
8 |
Module Resolution | 32*32Px |
9 |
Driving mode | 1/8 scans |
10 |
visual angle(Deg) | H:140/V:140 |
11 |
brightness | 5500 (cd/㎡) |
12 |
Grayscale | 14bit |
13 |
refresh frequency | 1920Hz |
14 |
Power consumption(W/㎡) | Max:760/ Average:260 |
15 |
Life span | 100000hours |
16 |
working voltage | AC 110V~220V+/-10% |
17 |
Frame change frequency | 60Hz |
18 |
Degree of protection | IP65 |
19 |
working temperature | -30℃--+60℃ |
20 |
Working humidity(RH) | 10%-95% |
21 |
Product certification | CCC、CE、ROHS |
